Oki C911 Disassembly & Reassembly Procedures

13
31
Open the eject assembly and pull the
drawer out from the printer.
32
Lift the blue lock tab and remove the fuser
by lifting it straight up.
33
Loosen the 9 screws on the rear shield
plate, slide the shield to the left and slide
the shield plate from the printer.
