Remove the 3 black screws at the top of
the metal guide, and the 4 silver screws as
shown at right and remove the metal guide
plate.
On the front of the printer, pull the right side door frame down.
Remove the black plastic cover on the
paper guide frame by removing 2 black
screws.
Gently re-close the right side door frame
Remove 1 silver screw from the front and 2
silver screws from the rear of the
registration plate.
