Remove the 4 screws (2 on the outside / 2
on the inside) of the cover below the
duplexer.
Remove the plastic cover.
Remove lower left cover which is held in by
2 screws and 4 tabs.
NOTE: Metal plate which was removed
in the previous step is still present in this
picture.
Remove the low voltage power supply
cover, which is secured by 3 screws and 4
tabs.
Gently lift the corner over the main power
switch.
