5 Basic Information
SPECIFICATIONS_____________________
RESETTING TO FACTORY DEFAULTS ________
To reset the wireless card to the factory default settings:
1. Turn off the printer.
2. Press and hold the TEST button on the wireless card while
turning the printer back on. Keep pressing the button until
Wait a Moment
Network Initializing
appears on the display.
3. Wait for
Ready to Print
to appear.
IEEE
•802.11b
•802.11g
SECURITY:
Authentication Encryption
WEP Shared Key WEP 64 or 128 bits
WPA-Home WPA-PSK TKIP
WPA-Enterprise EAP-TLS TKIP
PROTOCOL
TCP/IP
COEXISTENCE WITH WIRED
PRINT SERVER
• Both can work simultaneously as
independent interfaces
• Each has separate configuration (including
IP Address) and separate certificates.
• Packet routing is not performed between
the two.
