Oki MC363DN User Manual

Scanning > 65
Scan Setting
(cont.)
Image Settings
(cont.)
Background
Removal
Auto, OFF, 1, 2, 3,
4, 5, 6
Allows you to block out the
color background of the
image (assuming document
has a color background) -
such that the background
color is not printed.
Show-
Through
Removal
OFF, Low, Middle,
High
Adjusts the level of show-
through removal.
Note: It is available only
when “Background Removal”
is set to “Auto” and
“Document Type” is “Text” or
“Text&Photo”.
Resolution 75dpi, 100dpi,
150dpi, 200dpi,
300dpi, 400dpi,
600dpi
Allows you to select the
appropriate resolution.
Remember the higher the
resolution the bigger the file size!
Contrast -3, -2, -1, 0, +1,
+2, +3
Contrast setting
High: Enhance brightness
Low: Reduce brightness
Hue -3, -2, -1, 0, +1,
+2, +3
Red/green balance
adjustment.
Low: Enhance red.
High: Enhance green.
Saturation -3, -2, -1, 0, +1,
+2, +3
Saturation setting
High: Enhance image
sharpness
Low: Reduce hue
RGB Red: -3, -2, -1, 0,
+1, +2, +3
Green: -3, -2, -1,
0, +1, +2, +3
Blue: -3, -2, -1, 0,
+1, +2, +3
Adjust RGB contrast settings.
Use the arrow keys to
increment and decrement
the values and to move to
the next color setting.
File Name User defined
Use the on-screen keyboard to
enter an appropriate file name.
Subfolder User defined Enter the subdirectory where
the scanned document will
be stored.
Continuous
Scan
ON, OFF Allows you to continue
scanning more documents.
Allows you to construct a
single scan job from multiple
individual sheets or originals.
Refer to “Continuous scan
mode” on page 110 for
details.
Grayscale ON, OFF Select ON to print in
grayscale.
FEATURE OPTION DESCRIPTION

Oki MC363DN Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	12 s
Time to first copy (color, normal)	14 s
Copy speed (black, normal quality, A4)	30 cpm
Copy speed (color, normal quality, A4)	26 cpm
Scan to	CIFS, E-mail, FTP, HTTP, PC, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	-
Scan speed (black)	30 inch/min
Image formats supported	JPG, MMR, RAW
Document formats supported	PDF
Fax memory	8000 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	300
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	45000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Number of print cartridges	4
Page description languages	Epson FX, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, SIDM
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	880 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	9, 10, C5, DL, Monarch
Photo paper sizes	10x15, 12.5x17.5 cm
Custom media width	64 - 216 mm
Custom media length	90 - 356 mm
Paper tray media weight	64 - 176 g/m²
Non-ISO print media sizes	16K, Executive (184 x 267mm), Folio (media size), Index card, Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	4x6, 5x7 \
Multi-purpose tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Display	LCD
Product color	Black, White
Display resolution	320 x 128 pixels
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1170 W
Power consumption (off)	0.5 W
Power consumption (sleep)	1.5 W
Power consumption (PowerSave)	20 W
Power consumption (average operating)	570 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	509 mm
Width	427 mm
Height	444 mm
