Oki Microline 390 User Manual

(5) Card
Weight
: 100 Ibs (162.8 g/m2) or less
Thickness
: 0.008 inch (0.20 mm) or less
Size
: 5 x 8 inches (when cut apart)
Medium feed : Bottom paper feed only
(6) Label
Thickness
: 0.011 inch (0.28 mm) or less
Size
: ML390 Elite-8.5x3.25 inches(216x83 mm) or less
ML391 Elite- 15x3.25 inches(381 x 83 mm) or less
(7) OHP sheet (transparencies)
Thickness
: 0.004 inch (0.10 mm) or less
Size
: 8.5 x 11 inches (216 x 280 mm) or less
1.3.3 Physical specifications
(1) Outside dimensions
ML390 Elite :
15.67 inches (398)(W) x 4.57 inches (I 16)(H) x 13.58 inches (345)(D)
ML391 Elite : 21.73 inches(552)(W)x4.57inches(l16)(H) x 13.58inches(345)(D)
These dimensions do not include the platen knob, acoustic cover and paper separator,
(2) Weight
ML390 Elite : 18.5 lb (8.4 kg)
ML391 Elite : 22.3 lb(10.1 kg)
1.3.4 Power requirements
(1) input power
Single-phaseAC
Voltage
: One of the following as specified: 2201240 VAC + 10% - 10%
Frequency : 50/60Hz + 2%
(2) Power consumption
Operating : IlOVA
Idle
: 40VA
l-6

Oki Microline 390 Specifications

General

Print Technology	Dot Matrix
Number of Pins	24
Resolution	360 x 360 dpi
Print Resolution	360 x 360 dpi
Noise Level	55 dB
Connectivity	Parallel
Paper Handling	cut sheet
Emulations	IBM ProPrinter
Paper Width	4 to 10 inches
Weight	13 lbs
