Oki ML6300FB-SC User Manual

Consumables and accessories > 45
4. Hold the ribbon cartridge (1) with your fingers pressing on its ribbon guide (2) and
slope it up and out to remove it from the carriage.
5. Holding the ribbon cartridge (1) close to both ends, slope it up and out until it
unlocks then remove it along the direction indicated by the arrows.
6. Dispose of the cartridge in accordance with your local guidelines.
7. Remove the new ribbon cartridge from its wrapping and note the position of the
Ribbon Guide (1), Knob (2) and Pin (3).
1
2
1
1
2
3

Oki ML6300FB-SC Specifications

General

Color	No
Character pitch	10, 12, 15, 17, 17.1, 20 cpi
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	-
Fonts included	Courier, Roman, Swiss, Prestige, Gothic, Utility, Swiss Bold, Orator, OCR-A, OCR-B, HSD & Barcodes
Print technology	Dot matrix
Connectivity technology	Wired
Page description languages	Epson ESC/P2, IBM ProPrinter
Sound pressure level (printing)	58 dB
Print direction	Bi-directional
Mean time between failures (MTBF)	12000 h
Paper feed	Manual
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Serial (RS-232)
Windows operating systems supported	Yes
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	30 - 85 %
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	255 mm
Width	425 mm
Height	210 mm
