DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
5. Menu Functions
a. Output Type
Output Signal
1-5 V
4-20 mA
4-20 mA + HART
RS485 (Modbus)
b. LCD Display Unit
Display
mode
Details
PV
Process variable shows on main screen,
percentage and progress bar shows on main
screen
mA*
Current shows on main screen, percentage and
progress bar shows on main screen
%*
Percentage shows on main screen, percentage
and progress bar shows on main screen
Voltage
Voltage shows on main screen. Applicable only to
the DC model.
*Not applicable on the RS485 model.
c. Measuring Menu
Mark
State
URV
Upper range value, 20 mA
LRV
Lower range value, 4 mA
d. Damping Time
Units
Setting Range
S
0-100 Seconds
e. Unit
f. Analog Output Type***
***Applies only to 4-20 mA + HART models.
Unit
Definition
kPa
Kilopascal
MPa
Megapascals
BAR
BAR
PSI
Pounds per square inch
mmHg
Millimeter of mercury @ 0 ℃
mmH2O
Millimeter of water @ 4 ℃
mH2O
Meter of water @ 4 ℃
INH2O
Inches of water @ 4 ℃
FTH2O
Feet of water @ 4 ℃
INHg
Inches of mercury @ 0 ℃
mHg
Meter mercury column @ 0 ℃
TORR
Torr
mBAR
Millibar
g/cm2
Gram per square centimeter
kg/cm2
Kilogram per square centimeter
Pa
Pascal
ATM
Standard atmospheric pressure
OSI
Ounce per square inch
mm
Millimeter (Note1)
m
Meter (Note1)
Note1: Length unit need mark medium density
Parameters
Output Type
mA LINER
Linearity (default)
mA √
Square Root
