DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
g. Alarm Signal
Parameters
Alarm Signal
ALARM NO
None
ALARM H
20.8 mA
ALARM L
3.8 mA
h. Fixed Output
Parameters
Fixed Output Value
FIX/C NO
None
3.8000
3.8000 mA
4.0000
4.0000 mA
8.0000
8.0000 mA
12.000
12.000 mA
16.000
16.000 mA
20.000
20.000 mA
20.800
20.800 mA
i. Quick Menu
Parameter
Instruction
PV = 0
Set current output to zero value,
used to correct the error caused
by static pressure and
installation.
Zero adjustment
4 mA re-range with pressure
Span adjustment
20 mA re-range with pressure
Restore factory setting Restore backup data when error
