1 - DESCRIPTION OF THE APPLIANCE
1.1 - LIST OF THE COMPONENTS SUPPLIED (Fig.5)
The appliance is packaged singularly in a cardboard packaging.
The packaging can be transported by hand by two operators or loaded on a forklift.
Store the packaging singularly; do not stack it.
1. 
2. Window air conveyor outlet
3.       
versions where envisaged)
4. Flange cap (only for versions where envisaged)
5. Window suction cup
6. Use and maintenance manual
7. Remote control
8. Condensation discharge pipe
 
1.2 - IDENTIFICATION OF THE MAIN COMPONENTS (Fig.A)
21. Control panel
22. Air outlet grille
23. 
24. Plug for draining condensation water (connect
to a drain for heat pump operation, model HP
only)
25. Air inlet
26. Air outlet
27. Handle for moving
28. IR remote control receiver
