NOMENCLATURE

CKX31

Objectives

PlanCN 4X

PlanCN 10X

PlanCN 20X

PlanCN 40X

PlanCN 60X

PlanCN 100XO

Eyepieces (10X)

Binocular Tube (Fixed)

Microscope Frame

· CKX31SF

Lamp Socket

U-LS30-3

Illumination

Column (Fixed)

Phase Contrast Slider

· Pre-centered Ph slider: IX2-SLP

· Ph centering slider: IX2-SL

Ultralong Working

Distance Condenser

Revolving Nosepiece (Fixed)

Quadruple revolving nosepiece

Stage (Fixed)

· Stage extension plate: CK2-SS

· Mechanical stage: CK40-MVR

For brightfield observation:

#Dedicated objectives are required

for phase contrast observations

(see page 17).
