23
CKX41/CKX31
2. Illumination Built-in transmitted Koehler illumination
High-intensity halogen bulb 6V30WHAL (PHILIPS 5761)
(Average life time: Approx. 100 hr. when used as directed)
Output rating: 6 V 30 VA (DC)
Input rating: 100-120/220-240 V , 0.85/0.45 A, 50/60 Hz
SPECIFICATIONS
Item
Specification
CKX31 CKX41
1. Optical system UIS2/UIS (Universal Infinity System) optical system
3. Focusing mechanism Vertical movement of revolving nosepiece (stage height fixed)
Coarse and fine adjustment knobs (provided with rotation tension adjustment
mechanism)
Stroke per rotation (from focal point on stage surface): 7 mm upward and 2 mm
downward
4. Revolving nosepiece Quadruple positions (fixed)
Binocular Binocular tube (fixed):
Tilting angle 45°
Interpupillary distance adjustment 48 to
75 mm
Field number 20
Binocular tube U-CBI30-2:
Tilting angle 30°
Interpupillary distance adjustment 48 to
75 mm
Field number 20
Binocular tube U-BI30-2:
Tilting angle 30°
Interpupillary distance adjustment 50 to
76 mm
Field number 22
Trinocular Trinocular tube U-CTR30-2:
Tilting angle 30°
Interpupillary distance adjustment 48 to
75 mm
Field number 20
Trinocular tube U-TR30-2:
Tilting angle 30°
Interpupillary distance adjustment 50 to
76 mm
Field number 22
Tilting binocular
Tilting binocular tube CKX-TBI
Tilting angle 30 to 60°
Interpupillary distance adjustment 50 to
76 mm
Field number 20 (available only with
WHB10X)
6. Eyepiece 10X, field number 20 (fixed) WHB10X: Field number 20
WHN10X: Field number 22
5. Observation tube
Applicable
eyepieces
· WHB10X
U-CBI30-2
U-CTR30-2
CKX-TBI
· WH10X/WH15X
U-BI30-2
U-TR30-2
Tilting binocular tube U-CTBI
Tilting angle 30 to 60°
Interpupillary distant adjustment 48 to
75 mm Field number 18 (built-in 10X
eyepieces)
