2PV/2PW
1-2-12
1-2-3 Installing the expansion memory (option)
Procedure
1. Turn off the main power switch.
Caution: Do not insert or remove
expansion memory while machine
power is on.
Doing so may cause damage to the
machine and the expansion memory.
2. Remove the memory cover.
Figure 1-2-20
3. Release the hook and then open the
fan bracket.
Figure 1-2-21
Memory cover
Fan bracket
Hook
1
2
Service Manual
Y116650-5
To Next Page
Loading...
General
