viii ADVANCED OPERATION GUIDE
Originals and Paper Sizes
This section explains the notation used in this guide when referring to sizes
of originals or paper sizes.
As in A4, B5 and Letter, which may be used either in the horizontal or
vertical direction, horizontal direction is indicated by an additional R
character in order to indicate the orientation of the original/paper.
Icons on the Touch Panel
The following icons are used to indicate originals and paper set directions
on the touch panel.
Set direction Indicated size *
* The size of original/paper that can be used depends on the function
and source tray. For further details, refer to the page detailing that
function or source tray.
Vertical direction A4, B5, A5, B6,
A6, 16K, Letter,
Statement
For original/paper, dimension A is longer than B.
Horizontal direction A4-R, B5-R, A5-R,
B6-R, A6-R, 16K-
R, Letter-R,
Statement-R
For original/paper, dimension A is shorter than B.
B B
A A
Original Paper
B B
A
A
Original Paper
Set direction Originals Paper
Vertical direction
Horizontal direction
