Note: Please follow the Cash Drawer control signal design to control the Cash
Drawer.
Cash Drawer Control Command Example
Use Debug.EXE program under DOS or Windows98
Command
Cash Drawer
O 48C 04 Opening
O 48C 00 Allow to close
 Set the I/O address 48Ch bit2 =1 for opening Cash Drawer by “DOUT bit0”
pin control.
 Set the I/O address 48Ch bit2 = 0 for allow close Cash Drawer.
Command
Cash Drawer
I 48C Check status
 The I/O address 48Ch bit6 =1 mean the Cash Drawer is opened or not exist.
 The I/O address 48Ch bit6 =0 mean the Cash Drawer is closed.
