Olympia ROCK User Manual

79
OTHER IMPORTANT INFORMATION
TECHNICAL DATA
Rock
Other Important Information
Technical Data
Frequency GSM: 900 / 1800 Mhz, Bluetooth: 2�4Ghz
Sending power (max.)
GSM: 900 / 1800 Mhz: max� 2 W
Bluetooth (2�4Ghz): max� 100 mW
Power supply Input: 100 - 240 V, 50 - 60 Hz, 500 mA
Output: 5 V, 500 mA
Battery 3�7 V, 1000 mAh, up to 4 h; charge time
approx 2 hours to full charge
Standby Up to 120 hours
Max. talk time Up to 2 hours
Display 2�4" LCD with back-lighting
Interfaces microUSB
Dimensions 126 x 55 x 55 [mm]
Weight Approx� 148 g including battery
Permissible ambient
conditions
-10 °C to 40 °C at
30 to 75% relative humidity
Features Dual SIM, waterproof and dustproof in
accordance with IP 55
Subject to change without notice!

Olympia ROCK Specifications

General

Wi-Fi	-
Data network	GSM
SIM card capability	Dual SIM
2G bands (primary SIM)	900, 1800 MHz
Display type	LCD
Display diagonal	2.4 \
Display resolution	- pixels
Short Message Service (SMS)	Yes
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Form factor	Bar
Personal info management (PIM)	Alarm clock
Audio formats supported	MP3
Talk time (2G)	8 h
Battery voltage	3.7 V
Battery capacity	1000 mAh
Standby time (2G)	240 h
Battery recharge time	2 h
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	32 GB
Product color	Black, Yellow
Housing material	Metal
Protection features	Dust resistant, Waterproof
International Protection (IP) code	IP55
USB version	2.0
USB connector type	Micro-USB
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	30 - 75 %

Weight and Dimensions

Depth	11 mm
Width	55 mm
Height	126 mm
Weight	148 g
