Olympus 170 - Replacing the Battery; Handling Cautions

1. Open the buckle and
inside by sliding in the
direction of the arrow.
2. Insert a new battery
(CR1220) with the plus
mark showing on top
3. Attach the battery cover
by sliding in the direction
of the arrow
4. Close the buckle
Handling Cautions
• Never apply excessive force to
the remote control when
attached to the strap.
• Usable temperature range:
-10°C ~ 40°C (14°F ~ 104°F).
48
Replacing the Battery
remove the battery cover
