12.2 Guidance and manufacturer’s declaration –
electromagnetic immunity
The peristaltic pump unit is intended for use in the environment specified bellow. The
user of the peristaltic pump unit should assure its use in such an environment.
Immunity test IEC 60601-1-2
test level
Compliance level Electromagnetic
environment - guidance
Electrostatic
discharge (ESD)
according to
IEC 61000-4-2
± 6 kV
contact discharge
± 8 kV
air discharge
± 6 kV
contact discharge
± 8 kV
air discharge
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic materials, the
relative humidity should be
at least 30 %.
Electrical fast
transient / burst
according to
IEC 61000-4-4
± 2 kV
for power supply
lines
± 1 kV
for input/output
lines
± 2 kV
± 1 kV
The quality of the power
supply voltage should
comply with a typical
commercial or hospital
environment.
Surges
according to
IEC 61000-4-5
± 1 kV
for differential
mode
± 2 kV
for common mode
± 1 kV
± 2 kV
The quality of the power
supply voltage should
comply with a typical
commercial or hospital
environment.
Voltage dips,
short
interruptions and
voltage
variations of
power supply
input lines
according to
IEC 61000-4-11
< 5 %
for 5 s
< 5 %
for 0.5 periods
40 %
for 5 periods
70 %
for 25 periods
< 5 %
for 5 s
< 5 %
for 10 ms
40 %
for 100 ms
70 %
for 500 ms
The quality of the power
supply voltage should
comply with a typical
commercial or hospital
environment. If the user of
the peristaltic pump unit
requires continuous
operation during power
supply interruption, it is
recommended that the
peristaltic pump unit
should be powered from
an uninterruptible power
supply or a battery.
Magnetic fields
of mains
frequency
(50 / 60 Hz)
according to
IEC 61000-4-8
3 A/m 3 A/m Magnetic fields of mains
frequency should comply
with typical levels
characteristic of
commercial or hospital
environment.
