23
PHOTOMICROGRAPHY
7-1 Connecting to the Phtomicrographic Systems
}Use the CH-TR45 trinocular tube when performing photomicrography.
# Use the 45HA heat absorbing filter when using the PM10, PM20, or PM30 photomicrogtraphic system.
# Pay attention to the design and weight of a CCD camera when selecting one to use with this system. Stability and ease
of observation can be interfered with by inappropriate cameras.
1 Selecting the Light Path
Pull out he light path selector to choose the photomicrographic light
path. For details, refer to “ 3 Selecting the Light Path for the Observation
head ” in “ 5-3 Observation head ” on page 15.
C-mount
Video camera
Video adapter
MTV-3
Photomicrographic
system
PM-10M
OM camera back
Photomicro adapter L
MOM-L
Automatic photomicrographic system
PM-30
Automatic photomicrographic system
PM20
Automatic exposure photomicrographic
system PM-10AK
Photo eyepiece NFK
NFK photo eyepiece adapter
PM-ADF
Trinocular tube
CH3-TR45
Microscope body
CK40
To Next Page
