28
REFLECTED FLUORESCENCE SYSTEM FOR CKX41
Fuse replacement (Fig. 24)
#Set the main switch to “ ” (OFF) and unplug the power
cord before replacing fuses.
1. Remove each of the fuse holders 9 by turning it counter-
clockwise using a flat-blade screwdriver and pulling out.
2. Replace both fuses with new ones.
#Always use the designated fuses. Otherwise, a fire hazard
may result.
9
Fig. 24
Applicable fuses
U-RFTL50-100: T4A(H)250V
(LITTELFUSE 215004), 2 pieces
U-RFTL50-200: T2.5A(H)250V
(LITTELFUSE 215025), 2 pieces
