Olympus E-PL8 - Attaching a Lens to the Camera

15 EN
Preparation
1
Attaching a lens to the camera
1
Remove the rear cap of the lens
and the body cap of the camera.
1
2
Rear cap
2
1
2
Align the lens attachment mark
(red) on the camera with the
alignment mark (red) on the
lens, then insert the lens into
the camera’s body.
Lens attachment mark
3
Rotate the lens clockwise
until you hear it click (direction
indicated by arrow 3).
3
• Make sure the camera is turned off when attaching or removing the lens.
• Do not press the lens release button.
• Do not touch internal portions of the camera.
 Removing the lens cap
1
2
1
 Removing the lens from the camera
Make sure the camera is turned off when removing the lens.
While pressing the lens release button, rotate the lens in the
direction of the arrow.
2
1
Lens release button
Interchangeable lenses
Read “Interchangeable lenses” (P. 126) .
