CAUTION:
This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Setup
ID Input
Mode Selection
1
Press the ID INPUT key and the Patient Data screen appears on monitor.
2
Enter all the necessary data and click OK to proceed.
* ID input is mandatory to save data after examinations.
* When the EU-ME2 is integrated with the CV-190 or CV-180, ID input is not available on the EU-ME2 and patient data must be entered via the
CV-190 or CV-180 system.
ID INPUT Key Patient Data Screen
1
Press the B, FLOW and PW keys on the keyboard to select the B mode, FLOW mode and Pulse Wave Doppler mode,
respectively.
2
Press the ELST button to select Elastography mode.
* It is not possible to switch modes while in the FREEZE mode. Select modes in LIVE mode only.
* Refer to the separate guide regarding the FLOW mode selection (COLOR FLOW, POWER FLOW, and H-FLOW).
* Refer to the separate guide regarding the Elastography mode..
* The ELST button on the LCD touch panel is displayed in the upper right corner of the MAIN MENU (shown right after unfreezing).
* The ELST button will only appear on the EU-ME2 Premier Plus.
MODE Buttons (LCD)
MODE Keys
Elastography
Pulse Wave Doppler
FLOW Mode
B Mode
To Next Page
