SUCTION PUMP KV--5
13
5.2 Troubleshooting
Symptom Possible cause
Pump fails to operate Check that the unit is correctly connected to the power supply
and that the power switch illuminates when set to l.
Check the fuses, located within the pull-out fuseholder above the
power plug connector
NOTE: Always replace a fuse with one of the correct type and
rating. If a fuse continues to blow, contact Olympus.
The thermal cut-out within the windings of the pump motor may
have operated. Check the vents are clear. When the temperature
h
a
v
e
o
p
e
r
a
t
e
d
.
C
h
e
c
k
t
h
e
v
e
n
t
s
a
r
e
c
l
e
a
r
.
W
h
e
n
t
h
e
t
e
m
p
e
r
a
t
u
r
e
of the windings falls to an acceptable level normal operation will
resume. If the problem recurs, contact Olympus.
Pump operates but no suction or suction level is too low. Check that all connections are secured.
Check the unit is correctly connected to the endoscope or other
device.
Check that the microbial filter is not blocked and suction tubes
are corr ectly positioned and are not kinked, blocked or punctured.
Check the jar liner is not full and that the float mechanism (if
used) is not stuck in the closed position.
Check performance of the pump as per Section 5.1.
Check the vacuum regulator is set to the correct position.
Check all connections and tubing for air leakage.
NOTE: I
f
as
p
irated
f
luid or solid material has been drawn into the
N
O
T
E
:
I
f
a
s
p
i
r
a
t
e
d
f
l
u
i
d
o
r
s
o
l
i
d
m
a
t
e
r
i
a
l
h
a
s
b
e
e
n
d
r
a
w
n
i
n
t
o
t
h
e
unit, the pump will continue to operate, but the unit should be
returned to Olympus for inspection and repair.
5.3 Replacement parts & accessories
Fuse T1.25H (20mm) 220--240V units 7146299......................
Fuse T2.5H (20mm) 100--120V units 7146302.......................
Microbial filter (pack of 10) 7048271...............................
Power cable 230V (UK) 7145454.................................
Power cable 230V (Europe) 7145462..............................
Power cable 110V (USA) 7146311................................
Power cable 100V (Japan) 7146329...............................
Suction jar 1ltr K7503762.......................................
Suction jar 2ltr K7503763.......................................
Lid for single--use liner K7503761..................................
Lid with float mechanism K7503760................................
Single--use liner 1ltr pk 30 K7503428...............................
Single--use liner 2ltr pk 25 K7503430...............................
Patient connecting tube 2m pk 50 (Rest of World) K7503432..............
Patient connecting tube 2m pk 50 (Americas only) K7505595..............
Filter connecting tube 340mm pk 10 K7503486........................
Filter connecting tube 900mm pk 10 K7503657........................
Jar mounting kit Olympus WM--30/60 K7503555.......................
Jar mounting kit Olympus WM--D60/N60, TC range K7503556.............
Transit screw K3921028........................................
Fibre washer K3921029........................................
