Chapter 3 Cleaning, Disinfection and Sterilization Procedures
17
OSF-3 ENDOSCOPE REPROCESSING MANUAL
Channel Cleaning Adapter (MB-19)
Used to aspirate reprocessing fluids from the Distal End of the endoscope
through the Instrument Channel (see Figure 3.6).
Figure 3.6
AW Channel Cleaning Adapter (MB-107)
For preclearing ONLY. Connects to the Air/Water Valve port. When the adapter
valve is depressed, water is fed through the Air/Water channel. Air is
continuously fed when the adapter valve is not depressed (see Figure 3.7).
Figure 3.7
Inspection of Equipment
For inspection of other equipment than that mentioned below, refer to the
instruction manual for the equipment being used.
The cleaning brushes are consumable items. Should the
slightest irregularity be suspected, use a spare instead.
Using a defective brushes may cause equipment damage.
