4.2 Operation
TB-0545PC/IC/FC, TB-0535PC/IC/FC, TB-0520IC, TB-0510IC
INSTRUCTION MANUAL
Ch.4
4 Output mode
SEAL & CUT mode
• In the SEAL & CUT mode, stop the output after finding that the vessel or tissue is
transected.
• Always grasp a blood vessel in the middle of the grasping section.
• While coagulating and cutting tissue in the SEAL & CUT mode, put light tension on
tissue until it separates, and immediately stop the activation after the tissue is
separated.
Press and hold the SEAL & CUT button (purple) or the SEAL & CUT pedal (left pedal:
purple) of the footswitch to activate the output for coagulation/sealing and cutting. The
compatible electrosurgical generator produces the output tone during activation.
SEAL mode
• In the SEAL mode, SEAL output is automatically stopped following the SEAL complete
tone.
• For hemostasis only, apply the SEAL mode output.
• In the SEAL mode, grasp a bleeding tissue with the grasping section and the probe tip.
• Always grasp a blood vessel in the middle of the grasping section.
• If desiccated tissue is present on the probe tip in the SEAL mode output, activate the
SEAL & CUT mode output with the grasping section open so that the desiccated tissue
falls caused by the ultrasonic vibration.
Press and hold the SEAL button (blue) of the handswitch or SEAL pedal (right pedal:
blue) of the footswitch to activate the output for coagulation/sealing. The compatible
electrosurgical generator produces the output tone during activation.
5 After the SEAL & CUT output is stopped or the SEAL output is stopped automatically
with the SEAL complete tone, visually confirm that the tissue is completely
coagulated.
