5
SPECIFICATIONS
Item Specification
(1) Tube magnification 1X
(2) Maximum field number 22 (mm
)
(3) Drawing image magnification 16X (When there is an intermediate tube between the microscope and
drawing attachment, the magnification may be variable by ±3%.)
10X (When the U-DAL10X is used)
(4) Drawing field
352 mm ( 220 mm when the U-DAL10X is used)
(5) Focusing (on paper) Focusing collar system
(6) Optical axis height
BX40, BX50: 330.5 mm (When an additional intermediate tube is com-
bined, add the thickness of the intermediate tube.)
BX41: 333. 5 mm.
BX51, BX52 (Transmitted light specification): 340.5 mm (When an addi-
tional intermediate tube is combined, add the thickness
of the intermediate tube.)
(7) Focusing range Below desktop surface: About 50 cm
Above desktop surface: Up to near the mirror housing bottom.
(The magnification is variable.)
