Chapter 5 Operation
61
VISERA VIDEO SYSTEM CENTER OTV-S7V
• The “B.O.D.” menu displayed (see Figure 5.2) depends upon
the installed B.O.D.s. For example, when using a type B
OTV-S7V, only “DV/DVCPRO” and “DIGITAL CAPTURE” are
displayed on the video monitor.
• The number of “SWITCH ASSIGNMENT” displayed (see
Figure 5.2) depends upon the number of remote control
switches on the camera head or videoscope. For example,
when the OTV-S7H-N is connected, only “SW.1” and “SW.2”
are displayed on the video monitor.
5.2 Basic menu operation
Various functions can be set up or adjusted by controlling the menu switches
(see Figure 5.3) or keyboard (optional).
Figure 5.3
To Next Page
