WM--P1 SERIES WORKSTATIONS
3.2 WM- DP1 series mobile workstations
Product name WM-- DP1 mobile workstation
Dimensions (mm) Height: 1370 (scope in lowest position)
2140 (scope in highest position)
1160 (to top tray)
1826 max (with 19” LCD monitor in highest position)
Depth: 655
Width: 1100
Weight 120kg unladen, including fitted transformer.
Load capacity
(evenly distributed)
Top tray 10kg
Intermediate shelves 26kg each
Base panel 45kg
NOTE: Equipment stored on the mobile workstation should not exceed
the size o f the shelf.
Castors 4 x 125mm non--antistatic, two with brakes.*
Ambient temperature Storage: --40Cto+70C
(--40F to +158F)
Operation: 10 -- 40C (50 -- 104F)
Relative humidity 95% maximum @ 40C (104F) non--condensing
Atmospheric pressure
Storage: 23.5-- 106 kPa (3.4--15.37lbf/in
2
)
Operation: 70-- 106 kPa (10.15--15.37lbf/in
2
)
* UK workstations fitted with Antistatic castors from Oct 2007.
3.3 WM- T1 series separation transformers
Product name Olympus Separation Transformer
Identification Market Japan USA UK, Europe,
Rest of the world
Model No. MAJ-- 173 MAJ-- 174 MAJ-- 175
Part No. K10000289 K10000290 K10000291
Power input
requirements
Input voltage 100V 110--120V 220-- 240V
Frequency 50/60Hz 60Hz 50/60Hz
Power input (max) 1350VA 1300VA 1900VA
Power cable part No. K10001001 K10001002 K10001003 (UK)
K10001004 (Europe)
K10001005 (RoW)
Power output Maximum load 1250VA * 1250VA 1800VA
* Maximum 10A load per IEC socket outlet (MAJ--173 only)
Overload
protection
Input circuit breakers 2 x 15A 2 x 13A 2 x 9A
Output fuse T15AH T15AH T10AH
