37
3
EN
Playback
Playback
Settings relating to playback
[ Voice Playback ]
*1 *3
( ☞ P.61)
Only the voice portions
from a recorded audio file
are played back.
[ Noise Cancel ] *3
( ☞ P.61)
If recorded audio is difficult
to understand because of
noisy surroundings, adjust
the Noise Cancel setting
level.
[ Voice Balancer ]
*1 *3
( ☞ P.61)
When playing back a
recorded audio file, the
recorder compensates for
any low-volume portions
in the file.
[ Voice Filter ] *2 *3
( ☞ P.61)
The recorder has a Voice
Filter Function to cut low
and high frequency tones
during normal, fast, or slow
playback, playback tone,
and enable clear audio
playback.
[ Play Mode ]
( ☞ P.62)
You can select the
preferred playback mode.
[ Equalizer ] *4
( ☞ P.62)
When listening to music,
you can set your favorite
sound quality by adjusting
the equalizer setting.
[ Skip Space ]
( ☞ P.63)
The skip interval can be set.
[ Play Scene ]
( ☞ P.63)
Playback settings of your
choice can be saved to suit
different sound qualities
and playback methods.
*1 WS-813, WS-812 only.
*2 WS-811 only.
*3 Function active only in [ R e c o r d e r ] mode.
*4 Function active only in [ M u s i c
] mode.
Playback through the earphones
The earphones can be connected to the EAR
jack of the recorder for listening.
• When the earphones are used, the
recorder speaker is switched off.
Notes
• To avoid hurting your ears, turn down the
volume before inserting the earphones
into your ears.
• When using the earphones, do NOT set
the volume too high. Listening at very
high volume may lead to hearing loss.
To EAR jack
To Next Page
