63
DATE
MS-250SLPM-D-MSPEC 1
12/11/2015
REV.
5.667in
143.94mm
4.000in
101.60mm
1.600in
40.64mm
20.32mm
.800in
.800in
20.32mm
Both Sides
1/2 NPT
20.32mm
.800in
.800in
20.32mm
82.55mm
3.250in
.750in
19.05mm
4.45mm
.175in
1.425in
36.20mm
4X 8-32 UNC .375in[9.53mm]
.800in
20.32mm
.500in
12.70mm
DATE
MS-50SLPM-D-MSPEC 1
1/11/2016
REV.
1.600in
40.64mm
19.05mm
.750in
3.250in
82.55mm
4.45mm
.175in
1.425in
36.20mm
4X8-32 UNC .375in[9.53mm]
20.32mm
.800in
.500in
12.70mm
Both Sides
1/4 NPT
4.000in
101.60mm
5.067in
128.70mm
250 slpm approximate shipping weight: 3.2 lb.
50 slpm to 100 slpm approximate shipping weight: 2.4 lb.
FMA-1600A-LSS
0 – 50 slpm
0 – 100 slpm
FMA-1600A-LSS
0 – 250 slpm
