© OMICRON 2024 Page 19 of 25
Above configuration profiles are pre-configured for 5 A test current. This should be suitable for most cables
with a length of up to 5 km.
If the current was reduced during the injecting the test current as described in chapter 3.4 , it must
be also reduced in state 1 and state 2 of the loaded configuration profile.
4.3 Perform Measurement
The measurement must be performed 7 times, with different current loops, as shown in Table 2.
Clamp 1 (Red)
Clamp 2 (Black)
– L2
-L2
1 – L3
1
1-L3
2 – L3
2
2-L3
– E
-E
– E
-E
– E
-E
– E
-E
Table 2: Required measurement loops
7: Test sequence for 50 Hz (CABLE-50.occp)
