3.6 Emergency Stop button
Figure 3-5: Emergency Stop button
Pressing the Emergency Stop button immediately shuts off all current and voltage
outputs except for the Ext. Booster output.
A running test is terminated, the software does not accept any more entries and/or
commands.
Once the reason for the Emergency Stop is cleared and the Emergency Stop button
released, the test can be re-started by pressing the I/O (test start/stop) push-button
while in Test Card View.
DANGER
Death or severe injury caused by high voltage or current
The Ext. Booster connector is always galvanically connected to mains.
This also applies when no external booster is selected, the green status light (0) is on,
the outputs are turned off or the Emergency Stop button is pressed.
► Handle the Ext. Booster connector with extreme caution.
► Do not use any other booster cables than the ones supplied by OMICRON.
► Do not use booster cables that are frayed or damaged in any way.
WARNING
Death or severe injury caused by high voltage or current possible
Stopping a test does not shut off the CPC 80 outputs instantaneously. First, the currently
running test sequence finishes, then the test execution is stopped.
Most test cards finish the running test sequence with a predefined ramp function.
► Therefore, in a hazardous situation never press "Stop Test".
► Instead, use Emergency Stop.
