3.7 ePC Interfaces
Figure 3-6: Connectors on the right side of the CPC 100 and CPC 80
USB connector
Connector for
OMICRON safety
accessories
RJ-45 socket for connection to a PC or a network hub
Yellow LED
Data are being transferred
from/to the network.
Green LED
CPC connected to a PC or network
Red LED
For diagnosis
Serial interface for
connection to other
OMICRON devices
