OmiSmoke Components
Handset
The handset displays the results from each test on the LCD. Progress through the
tests is indicated on the LCD, while the 4 buttons allow for menu navigation and option
selection.
1. Test results printer
2. LCD
3. ‘Up’ Navigation button
4. ‘Down’ navigation button
5. ‘Accept’ button
6. ‘Reject’ button
OM0381
1 3
2
6
5
4
