♦ Rename is allowed only for presets that have been stored by the user. You can’t rename a
factory preset. You can give a modified factory preset a new Save As name, and then treat it
as a user preset.
♦ Delete is not allowed for factory presets.
Preset files can also be transferred between VOLT and your computer so you can backup im-
portant user presets, or transfer them to other VOLTs. See the File Transfer screen, later in this
chapter.
About the Latency Meta-buttons
All digital processing takes time, even though a single operation might be measured in micro-
seconds. VOLT uses a lot of processing. With every feature turned on, this can add up to a dozen
milliseconds or more. In most applications, it won’t be enough to be noticeable… but some
FM situations may require less latency. VOLT: FM and VOLT: HD let you fine-tune processes,
so you can best manage the trade-off between sound quality and latency for your station.When
you press VOLT: FM’s main PROCESSING button, two buttons appear on the function menu.
The lower one, Latency, reveals a special panel with two option buttons — High Quality (18.7
ms latency) and Low Latency (10.3 ms) — plus four additional controls for specific processing
functions.
6/4/2017 Remote Control
http://192.168.1.168/remote.html?sid=17161fbaecdc61b1128672a9475529fa 1/1
Remote | LiveWire | GPIO / Events | File Transfer | Update | Configuration | About | Logout
I/O PROCESSING
AES ANALOG AES LIVEWIRE COMPOSITE
INPUT OUTPUTS INITIAL AGC LIMITERS FINAL
PRESETS
QuickTweak
Latency
High Quality Low Latency
15kHz LPF
Enhancer Processing
Bass Girth Clip
Clipper Mode
AudioChameleon
BackEMF
BigFuse
CircuitBreaker
Electra
Fact_Test
GIGAWATT
HotWire
KILOWATT
MEGAWATT
MegaAmps
Load
Save...
Save As...
Rename...
Delete...
Latency Config
Choosing an option above will optimize the below settings for the given
mode. The controls can still be adjusted individually after a mode is
selected.
Current Preset: CircuitBreaker Current IO Config: AnalogInput
STATUS
V1.1FMLatencyPanel.pdf
The two option buttons act as “meta-controls”: they pre-set the function controls for either
maximum processing (all on) or lowest latency (all off).
The processor controls on VOLT: FM’s screen include:
♦ 15kHz LPF turns on a very sharp Input Low Pass filter so extremely bright programming
doesn’t cause issues in the following processor stages,
♦ Enhancer Processing lets the Initial Enhancers add features to your sound,
♦ Bass Girth Clip turns on the Bass Girth Clipper to enhance upper harmonics of bass notes,
♦ Clipper Mode High Quality adds even more distortion cancelling to the final clipper.
♦ VOLT: HD’s PROCESSING button’s Latency option has slightly different meta-controls:
HD Radio and Studio. These enable slightly different specialized mixes of these processors:
CHAPTER 5
| 33
BROWSER-BASED REMOTE CONTROL
