Technical Specifications
BOB-10A
Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 1060 W
Amplifier power: LF 300 W RMS + HF 2 x 300 W RMS at 4 ohms
LF speaker: 25 cm (10") with 50 mm voice coil
Frequency range: 45-250 Hz
Sensitivity: 100 dB
Maximum SPL: 125 dB
Signal input: Combination XLR/6.3 mm jack L/R and RCA L/R
Parallel output: XLR L/R
Satellite: Speaker L/R
Amplifier type: Class D
DSP: 48 Bit, 96 kHz sample freqency
DSP functions: Limiter, compressor, crossover and equalizer
Bluetooth: Version 2.0
Protection: Soft start, short-circuit, limiter, overcurrent, overheat
Controls: Level satellite L/R, level subwoofer, DSP mode, Phase reversal
switch, Bluetooth on/off, power on/off
Indicators: Fault, limit, signal, power
Cooling: Convection
Enclosure: 15 mm MDF with M20 flange (2 x), texture painting and steel grille
Dimensions (L x W x H): 470 x 300 x 430 mm
Weight: 16.5 kg
BOB-4
Rated power: 75 W RMS
Program power: 150 W
Components: 10 cm speaker (4") with 25 mm voice coil
Frequency range: 150-16000 Hz
Sensitivity: 90 dB
Maximum SPL: 109 dB
Impedance: 16 ohms
Connection: 1 x speaker and screw terminals
Enclosure: ABS with M8 threaded inserts, texture painting and steel grille
Dimensions (L x W x H): 160 x 150 x 158 mm
Weight: 1.7 kg
Specifications are subject to change without notice due to product improvements.
