Omnitronic MPZ SERIES - 10 Technical Specifications

29
10
TECHNICAL SPECIFICATIONS
MPZ Series
Power supply: 230 V AC, 50 Hz ~
Output power and power
consumption:
MPZ-120P: 120 W
RMS
, 120 W
MPZ-180P: 180 W
RMS
, 360 W
MPZ-250P: 250 W
RMS
, 500 W
MPZ-350P: 350 W
RMS
, 700 W
MPZ-500P: 500 W
RMS
, 1000 W
MPZ-650P: 650 W
RMS
,1300 W
Output type:
70 V, 100 V or 4-16 Ω
Microphone input:
5 mV, 600 Ω
Line input:
300 mV, 10 kΩ
Output: screw connectors
Frequency range: 80 Hz - 14 kHz
Distortion: 0.5 % (1 kHz)
S/N ratio: 85 dB (line), 75 dB (mic)
Protection: over current, short circuit, turn-on delay
Indicators: power, fault, level
Dimensions: 483 x 400 x 92 mm
Weight:
MPZ-120P: 9.5 kg
MPZ-180P: 10 kg
MPZ-250P: 11.5 kg
MPZ-350P: 14 kg
MPZ-500P: 16 kg
MPZ-650P: 20 kg
Playback format audio player: MP3
Available storage media: USB devices and SD(HC) cards up to 32 GB
File system: FAT32
Number of files: max. 999
Battery remote control: CR2025
