Omnitronix DL50 User’s Manual
Page 22
Data-Link DL50 - FTP Push Setup Menu
A) FTP Push Enable [OFF]
B) FTP Server Address [0.0.0.0]
C) Username [Default FTP Username]
D) Password []
E) Account []
F) Directory []
G) Minutes Between Push Attempts [1440]
H) Select Files to Push
I) Remote File Names
FTP Push Setup: FTP Push Enable is an on/off toggle for FTP push.
FTP Push Setup: FTP Server Address is the IP address of the FTP server to push to.
FTP Push Setup: Username/Password are the username and password settings for accessing the
remote FTP server.
FTP Push Setup: Account is a third login option used only on some FTP servers. Consult the
network administrator to see if this is necessary.
FTP Push Setup: Directory is the path used to upload the file(s). Leaving this option blank
uploads the files into the root login directory.
FTP Push Setup: Minutes Between Push Attempts has a valid range of 1 to 9999 minutes.
FTP Push Setup: Select Files to Push brings up the menu in the following example. Each item
in the menu is a toggle for the specified file.
Data-Link DL50 - FTP File Selection
A) Data File 1 [ON]
B) Data File 2 [ON]
C) Alarm File [ON]
FTP Push Setup: Remote File Names brings up the menu in the following example. Each item
in the menu allows the admin to set the new remote file name for uploaded files.
Data-Link DL50 - FTP File Names
A) Data File 1 [FILE1]
B) Data File 2 [FILE2]
C) Alarm File [ALARM]
FTP Autodelete automatically deletes records that are retrieved via the internal FTP server. This
function has no effect on FTP push operations, which always have autodelete enabled.
Real-Time Socket Setup displays the following RTS setup menu. A RTS is a Telnet connection
that allows a user to connect directly to the data file for any serial port or the alarms file. When
connected, the DL50 will immediately deliver all records stored within the file. Using real-time
