Chapter 4 - Setup
Manual Rev. 1.01 Page 31
No-Data 1 Alarm Settings: Delete Exclusion prompts for a date to delete. Upon entering a date
used in the exclusion list, it will be removed.
80% Full Alarm Settings displays a menu containing options pertaining to how to alert when the
memory allocated to storing data and alarm records reaches 80% of capacity.
Data-Link DL50 - 80% Full Alarm Settings
A) Alarm Enable [OFF]
B) Alarm Actions []
C) Alarm Message [80% Full]
80% Full Alarm Settings: Alarm Enable toggles the alarm on and off.
80% Full Alarm Settings: Alarm Actions defines the actions to perform on alarm.
80% Full Alarm Settings: Alarm Message is the string sent with trap actions.
Scheduled Event n Settings contains all of the settings for actions to occur on a regular,
predetermined basis.
Data-Link DL50 - Scheduled Event 1 Setup
A) Enable Event [OFF]
B) Event Actions []
C) Event Message [Event 1 Default Message]
D) Event Time Sunday [DISABLED]
E) Event Time Monday [DISABLED]
F) Event Time Tuesday [DISABLED]
G) Event Time Wednesday [DISABLED]
H) Event Time Thursday [DISABLED]
I) Event Time Friday [DISABLED]
J) Event Time Saturday [DISABLED]
K) Add Exclusion
L) Delete Exclusion
[]
Scheduled Event n Settings: Enable Event toggles the event on or off.
Scheduled Event n Settings: Event Actions defines the actions to perform on event.
Scheduled Event n Settings: Event Message is the string sent with trap actions.
Scheduled Event n Settings: Event Time Day of Week sets the time to perform the action on
each day of the week. These settings accept either a <SPACE> + <ENTER> to disable the event,
or a time in HH:MM 24-hour format.
Scheduled Event n Settings: Add Exclusion allows an administrator to add certain dates to
prevent scheduled events from occurring. After a MM/DD entry is made, it appears in the
brackets below option O.
Scheduled Event n Settings: Delete Exclusion prompts for a date to delete. Upon entering a
date used in the exclusion list, it will be removed.
