step 6 步骤六
CH1 󳖯󰴗
CH1 Linkage rod
CH2 󳖯󰴗
CH2 Linkage rod
CH3 󳖯󰴗
CH3 Linkage rod
󰷂六󲾣󲶋
(M1.6x3mm)x3
Socket screw
!
󱊹󰛠
CAUTION
󱆠󱃲󳺯󲸝󳇈󰺑󰶶󰈏󰸹󱬆󰴋󳕅󳜞󰰀󰳚󰵏󲢶󰳚󰵏
󳇈󰺑󰶶󰈏󰸹󲋸󲶋
Before each flight, please check whether the tail rotor and motor shaft are
loose. If loose, please check the tail rotor and tighten the screws!
󰄨󰏷󱠘󲶋
(M1.4x3mm)x3
Socket screw
󰈏󰸹󳪭
 Ø4.5xØ1.4x0.3mm)x1
Washer
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰈏󰮜󲗍
Tail Blade
󰈏󱬆󰴋
Tail Motor
󰈏󱬆󰴋󰅫󰑸
Tail Motor Mounting Panel
垂直翼
Vertical Stabilizer
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰷂六󲾣󲶋
M1.6x3mm
Socket screw
󰷂六󲾣󲶋
M1.6x5mm
Socket screw
󰷂六󲾣󲶋
(M1.6x5mm)x1
Socket screw
尾管
Tail Boom
