OMP Hobby M1 EVO - 1-09; 图纸和视图; 模型

9
EN
WWW.OMPHOBBY.COM
step 4 步骤四
󲶋󱆞 (M1.4)x1
M1.4 Nut
󰄨󰴋󰺁󱠪󲶋 (M1.4x8mm-L3)x2
Socket screw
󱠘  Ø1.4xØ3.5x0.5mm)x2
Washer
󳪭 (Ø1.4xØ2.4x4.95)x2
Copper sets
󰷂󲾣󲶋 (M1.4x6mm-L2)x1
Socket screw
3 SET
󰄨󰴋󰺁󱠪󲶋
(M1.4x3)x1
󱧔 (Ø2.5x4.8-M1.4)x3
Linkage Ball
Socket screw
󰄨󰴋󰺁󱠪󲶋
M1.4x3mm
Socket screw
舵机
Metal Servo
󱧔 Ø2.5x4.8-M1.4
Linkage Ball
󲠆󰴋󰨗󲞓
Servo Arm
󰄨󰴋󰺁󱠪󲶋
M1.4x8mm-L3
Socket screw
󱠘
Ø1.4xØ3.5x0.5mm
Washer
󲶋󳎮󰥸󲞓
Main Pitch Control Arm
󰄨󰴋󰺁󱠪󲶋
M1.4x6mm-L2
󳪭
Ø1.4xØ2.4x4.95mm
Copper sets
󰭭󱲩
Swash plate
󲶋󱆞 (M1.4)
M1.4 Nut
