OMP Hobby M1 EVO - 1-06; 图纸和视图; 模型

step 1 步骤一
!
󱊹󰛠
CAUTION
󲺖󲒕󲺖󰅝󰟡󱆠一󱃲󳺯󲸝󳇈󱸿󳅵󲶋󰰀󰏃󲛇󰵏
󳕅󰡐 (Ø2.5xØ6x2.6mm)x4
6
EN
WWW.OMPHOBBY.COM
Bearing-682ZZ
󰮜󲗍󰑸
Main rotor holder
󱠘 (Ø2.6xØ4.8x0.4)x2
Washer
󲸽  Ø2.6xØ5.9x0.8mm)x2
Washer
󳕅󰡐
Ø2.5xØ6x2.6mm
Bearing-682ZZ
󳕅󰡐
Ø2.5xØ6x2.6mm
Bearing-682ZZ
󳞢󰈯󰮜󲗍󰅫󰑸
Metal main rotor housing
󰿻󳕅 Ø2.5x25.6mm
Feathering shaft
Grease
󰿻󳕅󳙐󳳘
Ø2.45xØ4.95x1.4mm
Damper rubber
󱠘 -Ø2.6xØ4.8x0.4mm
Washer
󲸽
Ø2.6xØ5.9x0.8mm-2
Washer
󰷂󲾣󲶋
M1.6x3mm
Socket screw
󰿻󳕅󳙐󳳘
Ø2.45xØ4.95x1.4mm
Damper rubber
󰷂󲾣󲶋
(M1.6x3mm)x2
Socket screw
!
󱊹󰛠
CAUTION
󰿻󳕅󲶋󳫒󲋸󳇈󱊹󰛠󰸹󲛎󳔽󳹋󱬖
For the original assembled product, please confirm whether the screws have
been glued and will not loosen before each flight.
After the feathering shaft screw is locked, please note
that the rotor holder can rotate smoothly !
