OMP Hobby M1 EVO - 1-12; 图纸和视图; 模型

12
EN
WWW.OMPHOBBY.COM
step 7 步骤七
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󱺄󲑵󲓅󰴋󳑼󰎷
Frame Left Carbon Fibre
󱺄󲑵󲓅󰴋󳑼
Frame Right Carbon Fibre
󰴋󳑼󰵐
Frame Middle Plate
󲛫󰶇󰅚󲺖󰑸
Landing Skids Mount
󲛫󰶇󰅚󲺖󰑸
Landing Skids Mount
󰴋󳑼󰬀󰷂
Frame Pillar
󱬆󳇔󰅫󰬀󰶇
ESC Mount Bracket

O-Ring
󰄨󰏷󱠘󲶋
(M1.4x3mm)x10
Socket screw
 φ1*φ4.5*φ1.5  x2
O-Ring
倾斜盘相位座
Swash plate plastic phase seat
󰴋󰅫󰷂
Canopy Support
󰷂󲾣󲶋
M1.6x6mm
Socket screw
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰄨󰏷󱠘󲶋
M1.4x3mm
Socket screw
󰷂󲾣󲶋
(M1.6x6mm)x1
Socket screw
󰄨󰏷󱠘󲶋
(M1.4x3mm)x6
Socket screw
