Omron 3G3RX2 Series Instruction Manual

41
Compatibility Conditions of UL/CSA Standards
Required protection by Fuse and circuit-breakers
 200V class
 400V class
Model
3G3RX2
Fuse Circuit Breaker
Type
Maximum Rating Maximum Rating
Voltage (V) Current (A) Voltage (V) Current (A)
A2004 Class J or T 600 15 --- ---
A2007 Class J or T 600 30 --- ---
A2015 Class J or T 600 40 --- ---
A2022 Class J or T 600 40 --- ---
A2037 Class J or T 600 50 --- ---
A2055 Class J or T 600 100 --- ---
A2075 Class J or T 600 150 --- ---
A2110 Class J or T 600 150 --- ---
A2150 Class J or T 600 150 --- ---
A2185 Class J or T 600 200 --- ---
A2220 Class J or T 600 200 --- ---
A2300 Class J or T 600 300 --- ---
A2370 Class J or T 600 300 --- ---
A2450 Class J or T 600 400 --- ---
A2550 Class J or T 600 500 --- ---
Model
3G3RX2
Fuse Circuit Breaker
Type
Maximum Rating Maximum Rating
Voltage (V) Current (A) Voltage (V) Current (A)
A4007 Class J or T 600 15 --- ---
A4015 Class J or T 600 20 --- ---
A4022 Class J or T 600 30 --- ---
A4037 Class J or T 600 30 --- ---
A4055 Class J or T 600 75 --- ---
A4075 Class J or T 600 75 --- ---
A4110 Class J or T 600 75 --- ---
A4150 Class J or T 600 100 --- ---
A4185 Class J or T 600 100 --- ---
A4220 Class J or T 600 100 --- ---
A4300 Class J or T 600 200 --- ---
A4370 Class J or T 600 200 --- ---
A4450 Class J or T 600 200 --- ---
A4550 Class J or T 600 250 --- ---
B4750 Class J or T 600 300 --- ---
B4900 Class J or T 600 400 --- ---
B411K Class J or T 600 500 --- ---
B413K Class J or T 600 500 --- ---
