Omron A16 - Page 15

Pushbutton Switch A16 G-19
Pushbutton
Switches
Screw-Less Clamp
■ Operating Characteristics
Note: Lock stroke is only for alternate operation.
■ Contact Form
Item Screw-Less Clamp
Recommended wire size
0.5 mm
2
twisted wire or 0.8 mm-dia. solid wire
Usable wires and tensile
strength
Twi st ed wi re
0.3 mm
2
0.5 mm
2
0.75 mm
2
1.25 mm
2
Solid wire 0.5 mm dia. 0.8 mm dia. 1.0 mm dia. ---
Tensile strength 10 N 20 N 30 N 40 N
Length of exposed wire 10 ±1 mm
Type
Features
Pushbutton Switch
IP40 Oil-resistant IP65
SPDT DPDT SPDT DPDT
Operating force (OF) max. 2.45 N 4.41 N 2.94 N 4.91 N
Releasing force (RF) min. 0.29 N
Total travel (TT) Approx. 3 mm
Pretravel (PT) max. 2.5 mm
Lock stroke (LTA) min.
(See note.)
0.5 mm
Name Contact
DPDT
COM
NC
NO
