Appendix BSpecifications
164
Circuit Configuration
Units manufactured on or before January 28th, 2000
(manufacturing numbers 2810 or earlier*)
Units manufactured on or after January 31st, 2000
(manufacturing numbers 3110 or later*)
Output indicator
F indicator
OUT00
OUT07
COM
CN1
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
CN1
CN2
SW
OUT00
OUT07
COM
CN2
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
Indicator
switch/
fuse
blowout
detection
circuit
Output indicator
F indicator
OUT00
OUT07
COM
CN1
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
CN1
CN2
SW
OUT00
OUT07
COM
CN2
OUT08
OUT15
COM
Inter-
nal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
Indicator
switch/
fuse
blowout
detection
circuit
*Manufacturing Numbers
jjY9
Year: Last digit of calendar year; e.g., 1999→9, 2000→0
Month: 1 to 9 (January to September), X (October), Y (November), Z (December)
Day: 01 to 31
