Transistor Output Unit C200H-OD219 (64 Points)
Max. Switching Capacity 16 mA 4.5 VDC to 100 mA 26.4 VDC (see below)
Min. Switching Capacity None
Leakage Current 0.1 mA max.
Residual Voltage 0.8 V max.
ON Response Time 0.1 ms max.
OFF Response Time 0.4 ms max.
No. of Circuits 2 (32 points/common)
Internal Current Consumption 270 mA 5 VDC max.
Fuses Two 3.5 A fuses (1 fuse/common)
The fuses are not user-replacable.
Power for External Supply
220 mA 5 to 24 VDC10% min.
(3.4 mA × number of ON pts)
Weight 250 g max.
Dimensions D-shape
