Omron CJ Series Connection Guide

7
．
Serial Communications Connection Procedure
16
8
DATA is displayed on Main
Display.
Press the ZERO/SET Key once.
Check that the following set
value is displayed on
Sub-display.
Data length: 8bit (Default)
*If the value is different, change
the value by pressing the
↑
(UP) or the
↓
(DOWN) Keys.
Press the ZERORST/ESC Key
once.
The first menu shown in this
step is displayed again.
Press the
→
(RIGHT) Key once.
8blt
9
PARITY is displayed on Main
Display.
Press the ZERO/SET Key once.
Check that the following set
value is displayed on
Sub-display.
Parity: OFF (None: Default)
Press the ZERORST/ESC Key
once.
*If the value is different, change
the value by pressing the
↑
(UP) or the
↓
(DOWN) Keys.
The first menu shown in this
step is displayed again.
Press the
→
(RIGHT) Key once.
0ff
<Setting range>
8bit (Default)
/7bit
<Setting range>
OFF (Default)
/ODD/EVEN
