Wiring Section 3-4
3-4 Wiring
3-4-1 Terminal Arrangement
The signal names corresponding to the connecting terminals are as shown in
the following diagram.
CJ1W-AD041-V1
CJ1W-AD081-V1
Note 1. The number of analog inputs that can be used is set in the DM Area.
2. The input signal ranges for individual inputs are set in the DM Area. The
input signal range can be set separately for each input.
3. The AG terminals are connected to the 0-V analog circuit in the Unit. Con-
necting the input line shield can improve noise resistance.
!Caution Do not make any connections to the N.C. terminals.
Input 2 (+)
Input 2 (–)
Input 4 (+)
Input 4 (–)
AG
N.C.
N.C.
N.C.
N.C.
Input 1 (+)
Input 1 (–)
Input 3 (+)
Input 3 (–)
AG
N.C.
N.C.
N.C.
N.C.
B1
B2
B3
B4
B5
B6
B7
B8
B9
A1
A2
A3
A4
A5
A6
A7
A8
A9
Input 2 (+)
Input 2 (–)
Input 4 (+)
Input 4 (–)
AG
Input 6 (+)
Input 6 (–)
Input 8 (+)
Input 8 (–)
Input 1 (+)
Input 1 (–)
Input 3 (+)
Input 3 (–)
AG
Input 5 (+)
Input 5 (–)
Input 7 (+)
Input 7 (–)
B1
B2
B3
B4
B5
B6
B7
B8
B9
A1
A2
A3
A4
A5
A6
A7
A8
A9
