Omron CJ2H-CPU6*-EIP Series Connection Guide

7
．
Serial Communications Connection Procedure
19
7.3.2. Opening the Project File and Connecting Online with PLC
Start CX-Programmer, open the project file, and connect online with PLC.
Install CX-Programmer and the USB driver on Personal computer beforehand.
1
Turn ON PLC and Driver.
2
Start CX-Programmer.
*If the User Account Control
Dialog Box is displayed at start,
make a selection to start
CX-Programmer.
3
CX-Programmer starts.
4
Select Open from the File Menu.
5
The Open CX-Programmer
Project Dialog Box is displayed.
Select P659_CJ_Mod485_
Oriental_BLE_EV100.cxp and
click Open.
*Obtain the project file from
OMRON.
6
After opening the project file,
select Programs in the project
workspace.
